Toa N-8000 Series - Manual (Page 639)

8-39
Chapter 8 APPENDIX
5.31. RS-450 Indoor Substation
Note: The design and specifications are subject to change without notice for improvement.
• Accessories
No.6-32UNC x 18 .................................................. 4
Machine screw M4 x 25 ......................................... 4
5.32. RS-460 Indoor Vandal-Resistant Substation
Note: The design and specifications are subject to change without notice for improvement.
• Accessories
No.6-32UNC x 18 .................................................. 4
Machine screw M4 x 25 ......................................... 4
Call Button Momentary (Emergency call: Press twice within 400 ms.)
Rated Input 1 W
Internal Speaker Cone-type
Internal Microphone Electret condenser type
Wiring Twisted pair cables (2-pair)
Transmission Range 1000 m/ø0.5 mm (AWG24), 1500 m/ø0.65 mm (AWG22),
2000 m/ø0.9 mm (AWG19)
Operating Temperature –10 to +50°C (Temperature range not to freeze the speaker and switch)
Finish Panel: Stainless steel, hairline
Call button: Resin, black
Dimensions 120 (w) x 120 (h) x 41.5 (d) mm
Weight 510 g
Applicable Box 2-gang electrical box: YC-302 (option)
Call Button Momentary (Emergency call: Press twice within 400 ms.)
Rated Input 1 W
Internal Speaker Cone-type
Internal Microphone Electret condenser type
Wiring Twisted pair cables (2-pair)
Transmission Range 1000 m/ø0.5 mm (AWG24), 1500 m/ø0.65 mm (AWG22),
2000 m/ø0.9 mm (AWG19)
Operating Temperature –10 to +50°C (Temperature range not to freeze the speaker and switch)
Housing Protection BS EN62262: 2002: IK02 equivalent
Finish Panel: Stainless steel, hairline
Call button: Metal, silver
Dimensions 120 (w) x 120 (h) x 49.5 (d) mm
Weight 540 g
Applicable Box 2-gang electrical box: YC-302 (option)
