Introduction
The following areas of the Zodiak Main panel use delegation:
• Keyers subpanels
• Key bus source selection rows
• Joystick subpanel
• E-MEM numeric keypads in each M/E
• PVW/AUX bus source selection
• Menu panes
Automatic Subpanel Delegation
The Zodiak system is designed so that when an operator activates a partic-
ular object, one or more subpanels will automatically delegate to control
the specific object involved. This allows the operator to quickly access the
necessary controls without having to select them manually.
The subpanels that are auto delegated and the functions for initiating del-
egation are outlined in
Table 1 .
Momentary Delegation
An operator may sometimes have subpanel controls delegated to a certain
object, but need to make a quick change to a different object. For example,
a Keyers subpanel delegated to Keyer 1 may be temporarily delegated to
Keyer 3 to make a quick adjustment. This is done by holding down the
Keyer 3 button for a preset period. If the user makes an adjustment to
Keyer 3 within the time allowed, the timer will reset, otherwise, after a
period of no activity applied to Keyer 3, the delegation will return to the
original delegation, Keyer 1. A user preference sets the hold down delay.
Table 1. Subpanel Delegation
Subpanel Delegated Function Initiating Delegation
Keyer Subpanel
Putting a key on-air with Key 1 – 4 Mix button in Transition subpanel
Selecting a keyer on Key Bus delegate subpanel (except for Util or Macro)
Selecting a key as the next transition in a Transition subpanel
Key Bus Delegate Subpanel
Putting a key on-air with Key 1 – 4 Mix button in a Transition subpanel
Delegating a keyer in the Keyers subpanel
Selecting a key as the next transition in a Transition subpanel
Joystick Subpanel
Selecting the Int DPM button on a Keyers subpanel
Delegating a Keyer subpanel with an active preset pattern
Delegating a Keyers subpanel to key layer with active Transform Engine
Activating a Transform Engine
Activating a wipe with an active border
