134 Zodiak — User Manual
Section 3 — Control Surface Description
E-MEM Readout Display
The E-MEM readout display has 16 alphanumeric characters, and is used
to show the status of the current register status, display messages, and
prompt the user.
When displaying the status of the current effect, the first readout character
position is either blank or indicates with an “L” that the register is locked.
The second and third positions indicate the bank number selected for the
next action. The current effect number and name follows. A typical display
is shown in
Figure 85 . The full 16 character name is displayed for five
seconds when a register is recalled with a name longer than 9 characters.
Figure 85. E-MEM Readout Display of Current Effect
The E-MEM readout display prompts the operator for time entry during
Transition Rate operations. The readout can also display messages to the
operator. For example, if an attempt is made to alter a locked register the
readout will display Reg is locked for five seconds. Typical readout
displays are shown in (
Figure 86 ).
Figure 86. E-MEM Readout Display of User Prompts
LB2 23 Name
0618_01_65_r0
Lock
Status
Selected
Bank Number
Current Effect Name
(First 9 Characters)
Current Effect
Number
Auto = 2:0 Reg is locked
0618_01_66_r0
Time Entry Prompt User Message
