Zodiak — User Manual 189
Eng Setups Menus
Router Interface Setup Menu
The Router Interface Setup menu ( Figure 127 ) is used to set the IP
Address(es) the Zodiak system will use to communicate to the external
router. The Connection Status indicator is red when communication is not
detected, and is green when communication is established.
Figure 127. Router Interface Setup Menu
See the separate Zodiak Installation and Service Manual for specific configu-
ration information.
