352 Zodiak — User Manual
Section 5 — System Operation
Figure 249. Video Processor Frame Front, Power Switch (Door Open)
CAUTION The front door of the Zodiak Video Processor frame must remain closed
during normal system operation for proper cooling airflow.
Figure 250. Main Panel, Lid Open
8125_00_02_r0
ON OFF
Power Switch
Main Power Supply
On/Off Switch
Redundant Power Supply
On/Off Switch
8125_00_03r0
