334 Zodiak — User Manual
Section 4 — Menus Overview
scope’s border will turn white to show that Red is attached to Blue.
Changing from Blue to either Green or Red in the Color Corrector Transfer
Function pane will cancel the attachment.
Touching the Reset to Unity button will reset all attached components.
Effects Send Menu
The Effects Send menu is accessible from the M/E Menu by touching the
Effects Send button ( Figure 235 ).
Figure 235. Effects Send Menu
The buttons on this menu activate the Int DPM Effects Send loop on each
keyer of each M/E. This menu allows you to turn the Effects Send loop on
and off without having to first delegate that keyer on the Main panel.
Activating Effects Send is also a necessary precursor to using the Glow fea-
ture, which is standard on Zodiak systems.
