452 Zodiak — User Manual
Section 5 — System Operation
modules which are in the video path for each switcher input can be
assigned to Zodiak Menu panel knobs. The user is then able to control
those modules directly from the Zodiak system.
Refer to the separate Newton Instruction Manual and NetConfig Instruction
Manual for specific information about how to configure the Newton con-
trols. These manuals are included on the Zodiak Documentation CD, and
are available for download from the Thomson Grass Valley website.
External Device Newton Menu Description
Once configured, module parameters can be adjusted on the Zodiak
External Device Newton menu, which is accessed by touching
Extern Device ,
Newton ( Figure 299 ).
Figure 299. External Device Newton Menu
Selection of a module parameter to control is mediated though the Zodiak
source selection mechanism. By selecting a source on the currently dele-
gated Preview bus of the Zodiak’s Main panel, the source’s physical input,
and that input’s associated Newton channel controls are activated on the
Zodiak’s External Device menu.
