178 Zodiak — User Manual
Section 4 — Menus Overview
To choose a different Linked bus source for same source mapping, touch
the Linked Bus Source data pad to go to the Bus Linking menu selection
menu. Select the desired Linked Bus source from the scrolling list, then
touch
Display Shortcut Menu to return to the Shortcut menu. The Linked Bus
source you selected is now displayed in the data pad and can be mapped
to all the Controlling bus sources with the
Set button.
Copy Link Mapping Table
The Link Mapping table of one bus can be copied to another bus. Touching
the From This Bus and To This Bus data pads brings up the bus picker.
Once the desired buses have been selected, touch the
Copy button.
Note Link Mapping tables are active on Controlling buses only. If a list is copied to
a Linked bus, the data is transferred but the table is ignored as long as that
bus is not a Controlling bus. The Link Mapping table will become active on
that bus should it later become a Controlling bus.
Display All Links Menu
Touching the Display All Links button on the Bus Linking menu brings up a
scrolling list of all the defined bus links ( Figure 116 ). This can be used to
help manage the links. Buses that are not linked are not shown.
Figure 116. Bus Link Status
