E-MEM (Effects Memory)
The work buffer actually holds a copy of some of the effect register infor-
mation. When an operator changes a control setting manually, the work
buffer settings change but the effect register data itself remains unaltered
(
Figure 32 ).
Figure 32. Work Buffer Operational Change
When an effect is learned, the current operational settings in the work
buffer are loaded into the specified effect register, overwriting any infor-
mation that was in that register. If a register different from the current
effect is learned, the information is loaded into it and that register becomes
the current effect. In this case the original effect register will not be altered,
and can be instantly recalled to return the system to its earlier state.
(
Figure 33 ).
Figure 33. Learn Operation Changes Effect Register
Effect registers can be locked to prevent them from being altered, and they
can be saved to disk and reloaded and recalled for use at a later time.
