32 Installing the SmartServer Products
If you are using LNS mode, or if you are using EES to convert binary log files to CSV format, you
must install either an OpenLNS Server or an LNS Server. The OpenLNS Server is included with the
OpenLNS Commissioning Tool and other OpenLNS tools. The LNS Server is included with the
LonMaker Integration Tool and other LNS tools. If you do not have either server, you can download
the OpenLNS Server from www.echelon.com/openlns.
To install the Echelon i.LON Enterprise Services, click the Echelon SmartServer 2.2 SP – Install
Wizard button in the taskbar to return to the SmartServer 2.2 installer, click Echelon SmartServer 2.2
SP Enterprise Services in the Install Products dialog, and then follow the on-screen instructions.
See the Echelon Enterprise Services 2.2 User’s Guide for more information on installing the EES 2.2
software.
After the Echelon Enterprise Services has been installed, the Tomcat 6 Server starts and an EES tray
tool (
) is added to the notification area of your desktop. If you have installed an OpenLNS Server or
LNS Server, the LNS Proxy Web service is enabled and ready for setup on your SmartServer. For
instructions on setting up and troubleshooting the LNS Proxy Web service, see Adding an OpenLNS
Server to the LAN section in Chapter 3, Configuring and Managing the SmartServer.
For more information on using the i.LON Admin Server and using the EES tray tool, see the Echelon
Enterprise Services 2.2 User’s Guide.
Installing Echelon i.LON Vision Software
You can install the i.LON Vision 2.2 software to create custom 2.2 SmartServer Web pages for
monitoring and controlling your networks.
To install the i.LON Vision 2.2 software, click the Echelon SmartServer 2.2 SP – Install Wizard button
in the taskbar to return to the SmartServer 2.2 installer, click Echelon i.LON Vision SmartServer 2.2
SP in the Install Products dialog, and then follow the on-screen instructions. See the i.LON Vision
2.2 User’s Guide for more information on installing this software.
Installing Echelon NodeBuilder Resource Editor
You can install Echelon NodeBuilder Resource Editor 4.02 and LonMark Resource Files 14 to view,
create, and modify device resource files.
To use the new fast data log transfer feature, the device resource files for the subject data points must
be installed on your computer running EES 2.2. You must also install an OpenLNS Server or LNS
Server to use the new fast data log transfer feature. If you installed an OpenLNS Server, you already
have the version 14 Standard Resource File Set. You can manually copy any user-defined device
resource files to the LonWorks\types\user\<company> folder to your EES 2.2 computer. If you send
binary data logs from your SmartServer to be converted to CSV format and the device resource files
for the subject data points are not present, the conversion will fail.
To install the Echelon NodeBuilder Resource Editor, follow these steps:
1. Click the Echelon SmartServer 2.2 SP – Install Wizard button in the taskbar to return to the
SmartServer 2.2 installer, click Echelon NodeBuilder Resource Editor in the Install Products
dialog.
2. The Welcome window of the NodeBuilder Resource Editor installer opens.
