Configuring and Managing the SmartServer
6. Copy all the folders and files in the LonWorks\iLon100\images\iLon100 4.02 folder on your
computer to the root directory of the SmartServer flash disk.
7. Reboot your SmartServer by entering the reboot command in the console application.
Downgrading the SmartServer Firmware to i.LON 100 e3 Version
You can downgrade the firmware on your SmartServer to the i.LON 100 e3 version via FTP. To
downgrade the firmware on your SmartServer, follow these steps:
1. If the SmartServer 2.2 software is installed on your computer, uninstall it.
2. Install the i.LON 100 e3 software from the i.LON 100 e3 CD.
3. If you have not already installed i.LON 100 e3 SP3 or i.LON 100 e3 SR3 on your computer,
download and install i.LON 100 e3 SP3 from
4. Format the SmartServer flash disk using the bootrom console following these steps:
a. Enter the reboot command in the SmartServer console application.
b. When the console reads “Press the ‘!’ key to stop auto-boot”, press ‘!’. The
SmartServer will enter the bootrom state, halting all applications.
c. Enter the format command in the bootrom application. The SmartServer will automatically
reboot.
See Appendix B, Using the SmartServer Console Application, for more information on using the
bootrom and console applications.
5. Update the bootrom on the SmartServer following these steps:
a. In the browser of an FTP client such as Core FPT, WS FTP Pro, and Cute FTP, enter the FTP
URL of your SmartServer (ftp://192.168.1.222, for example).
b. Enter the FTP/Telnet user name and password for accessing your SmartServer via FTP.
c. Copy the bootrom.upd file in the LonWorks\iLon100\images\BootROM 3.03 folder on your
computer to the root directory of the SmartServer flash disk.
d. Enter the update bootrom command in the SmartServer console application. If the
bootrom file name is different than the default (bootrom.upd), specify the actual file name as
an additional parameter.
Note: Do not interrupt the bootrom update process. Doing so will render the SmartServer
unable to boot. If this happens, you will need to ship your SmartServer back to Echelon to be
repaired.
e. After the bootrom update has been completed, enter the reboot command in the
SmartServer console application.
6. When the reboot is complete, format the SmartServer flash disk again as described in step 4. After
the reboot is done, the SmartServer will be running the e3 bootrom.
7. Copy either the e3 SR3/SP3 firmware in the LonWorks\iLon100\images\iLon100 3.03 folder on
your computer or an existing e3 firmware backup to the root directory of the SmartServer flash
disk.
8. Reboot the SmartServer using the reboot command in the SmartServer console application.
When the reboot is complete, the SmartServer will be running the e3 firmware.
Migrating an e3 Network Configuration to the SmartServer
You can move a network configuration from an i.LON 100 e3 Server to the SmartServer. Integrating
the SmartServer with an existing network configuration lets you implement the new network
