Multi-Service IronWare Switching Configuration Guide 305
53-1003036-02
802.1ag over PBB OAM
11
• Link-trace, loopback and delay-measurement for ISID is supported.
• SVLAN keep-mode is supported.
• When MEP is configured on a VPLS instance with sub-second CCM timer, the MIP flooding
should be turned off. When there is no MEP and it is a sub-second-timer, then dot1ag flooding
should be turned on.
Brocade#show cfm
Domain: D2
Index: 2
Level: 1
Maintenance association: MA
Ma Index: 1
CCM interval: 10000 ms
PBB-VPLS ID: 100
Priority: 3
MEP Direction MAC PORT PORT-STATUS-TLV
==== ======== ========= ====== ==============
10 DOWN 0012.f2f7.3901 ethe 1/2 N
MIP VLAN/VC Port Level MAC
==== ======== ===== ===== ==========
100 1/1 1 0012.f2f7.3901
200 1/2 1 0012.f2f7.3901
In the following example, MIP is created for BVLAN not for ISID.
Brocade# show cfm connectivity
Domain: D2 Index: 2
Level: 1
Maintenance association: MA
MA Index: 1
CCM interval: 10000 ms
PBB-VPLS ID: 100
Priority: 3
RMEP MAC VLAN/ISID AGE PORT SLOTS STATE
==== ========== ========= ===== ===== ====== ======
1 0012.f2f7.3861 1000 72320 1/2 1 OK
802.1ag Port Status TLV
The Port Status TLV indicates the ability of the Bridge Port on which the transmitting MEP resides to
pass ordinary data, regardless of the status of the MAC.
NOTE
Port Status TLV is not be supported for LINK MA.
MEP configuration provides support for port status TLV.
Syntax: mep mep-id [ up | down ] [tlv-type tlv-type-value] [vlan vlan-id ISID isid port port-id | vlan
vlan-id port port-id | port port-id ]
The tlv-type-value should be set to the port-status-tlv.
