Page 349

Rockwell Automation Publication IASIMP-QS019E-EN-P - August 2013
349
Controller, Network, and Device Configuration Without the DMAT Wizard
Appendix G
Import and Configure E3 Plus Device Modules
Follow these steps to add preconfigured E3 Plus device logic modules to your Logix Designer project.
1.
Expand the Tasks folder in your Controller Organizer and right-click the Main Task folder.
2.
Choose Import Program.
3.
Navigate to the 4-Controller Logic folder within the toolkit’s files folder and open the 03_Device Modules
folder.
Your personal computer’s harddrive path is
C:\Program Files\RA_Simplification\DMAT\B-Files\4-Controller Logic.
