Fault Indication View
The Alarm button indicates a
drive fault condition and activates
the fault diagnostic views.
Fault Indication View
To access the detailed fault information and action displays, press the alarm button on the toolbar.
Toolbar Button
Color Indicator
Description
Action
Alarm
Grey
Normal state
None
Flashing yellow
Fault
Follow fault action screen
Current Fault
Indicators
Flashing Fault
Indicator
Close
Button
General Status
Indicators
Alarm Indicator
CIP Motion Drive
