Rockwell Automation 193 Drives and Motion Accelerator Toolkit Quick Start User Manual
Page 327

Rockwell Automation Publication IASIMP-QS019E-EN-P - August 2013
327
Controller, Network, and Device Configuration Without the DMAT Wizard
Appendix G
The Module Properties dialog box opens.
4.
On the Drive tab, click the Connect to Drive icon.
The Differences Found dialog box opens.
5.
Click Download.
Project parameters transfer to the drive.
Following download, the Module Properties dialog box displays green Drive Connected status indicator
and soft starter information is displayed. If not, follow other version compatibility update dialog boxes to
connect to soft starter.
6.
Click OK.
7.
Click
to save your Logix Designer application file.
