FactoryTalk View ME Configuration
Chapter 5
Design From an Existing HMI Application File
If your existing HMI application file is not too extensive, it may still be more efficient to start from the
preconfigured HMI application file and copy your existing application displays, parameter files, and alarm
messages. Refer to Design From a Preconfigured HMI Application File starting on
Otherwise, follow the steps in this section to add the HMI components to your existing FactoryTalk View
Machine Edition application file.
Open Your Existing HMI Application File and Add Displays
1.
Determine the required faceplates for your application based on the Determine the required faceplates for
your application based on the table. table.
TIP
Only one faceplate display is required for devices/modules of the same type.
Faceplate Displays
Faceplate Display Name
Parameter File
Supported Devices/Modules
Supported PanelView Plus
Terminals
CIPMotion_Faceplate
CIPMotion_Parameter
Kinetix 6500, Kinetix 5500, Kinetix 350 and
PowerFlex 755 drives configured as CIP Motion drives
All
E3Plus_Faceplate
E3_Parameter
E3 Plus overload relay
E3Plus_Faceplate_Energy
K300_Faceplate
K300_Parameter
Kinetix 300 drives
PowerFlex_4_40_400_Faceplate
PF_Parameter
PowerFlex 4, PowerFlex 40, and PowerFlex 400 drives
PowerFlex_40P_Faceplate
PowerFlex 40P drives
PowerFlex_70_700_Faceplate
PowerFlex 70EC and
PowerFlex 700VC drives
PowerFlex_70_700_Faceplate_Energy
PowerFlex_700S_700S2_Faceplate
PowerFlex 700S2 drives
PowerFlex_700S_700S2_Faceplate_Energy
PowerFlex_753_755_Faceplate
PowerFlex 753 and
PowerFlex 755 drives
PowerFlex_753_Faceplate_Energy
PowerFlex_755_Faceplate_Energy
PowerFlex_525_Faceplate
PowerFlex 525 drives
PVP1000_AlarmHistory_Faceplate
Not Required
All devices
• PanelView Plus 700
• PanelView Plus 1000
• PanelView Plus 1250
(1)
• PanelView Plus 1500
(1) The PanelView Plus 1000 Machine, Alarm History, and Equipment Status faceplate displays are sized at 640x480 (VGA) resolution. If full-sized displays are desired, open display, select all
(objects), group, and resize group. Some text editing for new display size may also be required.
PVP1000_EquipmentStatus_Faceplate
EquipmentStatus_Parameter
PVP1000_Startup_Faceplate
Startup_Parameter
Machine logic module
PVP1000_StateDiagram_Faceplate
StateDiagram_Parameter
Machine logic module (states)
PVP600_Startup_Faceplate
Startup_Parameter
Machine logic module
• PanelView Plus 400
• PanelView Plus 600
SERCOS_Faceplate
SERCOS_Parameter
Kinetix 2000, Kinetix 6000, Kinetix 6000M,
Kinetix 6200, Kinetix 7000, and Ultra3000-SE drives
All
SMC_50_Faceplate
SMC_50_Parameter
SMC_50 soft starters
SMC_50_Faceplate_Energy
