14 Rockwell Automation Publication IASIMP-QS019E-EN-P - August 2013
Preface
Conventions
Required Software
Convention Meaning Example
CIP Motion
Used as an abbreviation for Integrated Motion on the EtherNet/IP network. This term describes
Rockwell Automation servo drives and high-power AC drives that use CIP Motion and CIP Sync
technology from ODVA, all built on the Common Industrial Protocol (CIP) communicating over
the EtherNet/IP network. Two drive platforms that apply are Kinetix® 6500 servo drives and
PowerFlex 755 AC drives when used on the EtherNet/IP network.
CIP Motion Drive Configuration
Click
Click left mouse button once (assumes cursor is positioned on object or selection). Click button
to initiate action.
Click Browse.
Double-click
Click left mouse button twice in quick succession (assumes cursor is positioned on object or
selection).
Double-click the H1 icon.
Right-click Click right mouse button once (assumes cursor is positioned on object or selection). Right-click the Fieldbus Networks icon.
Drag and drop
Click and hold the left mouse button on an object, move the cursor to where you want to move
the object, and release the mouse button. Drag and drop the desired block into the Strategy
dialog box.
Select Click to highlight a menu item or list choice. From the pull-down menu, choose H1-1.
Check/uncheck Click to select a checkbox option.
Check Consider Case if you want to conduct a case-sensitive
search.
> Shows nested menu selections as menu name followed by menu selection. Click File >Page Setup>Options.
Expand Click the + to the left of a given item /folder to show its contents. In the H1-1 dialog box, expand FFLD.
Enter Used when you can type from the keyboard or choose from a list. Enter the catalog number of the product.
Type Used when the only option is to type from the keyboard. Type the catalog number of the product.
Press
Press a specific button on the PanelView™ terminal or other component with touch-screen
technology.
Press Axis Control.
Rockwell Automation Software Cat. No. Version Required For
Studio 5000™ Logix Designer application
9324-RLD300xxE
21.00 or later
All Kinetix and PowerFlex drive
applications RSLogix™ 5000
• ControlFLASH™
• BOOTP/DHCP utility (EtherNet/IP)
• RSLinx® Classic
19.00 or later (1)
(1) When Kinetix 350 servo drives are used, version 20.00 or later is required.
FactoryTalk View Studio for Machine Edition
• FactoryTalk Services
• RSLinx Enterprise
• RSLinx Classic
9701-VWSTMENE 5.1 or later PanelView Plus terminals
Motion Analyzer Rockwell Automation Configuration and Selection Tools
website
http://www.rockwellautomation.com/en/e-tools
or ask your Rockwell Automation sales representative for the
Product Selection Toolbox DVD
5.2 or later Drive/motor sizing
ProposalWorks™ 7.5 or later Bill of materials development
Drives and Motion Accelerator Toolkit DVD IASIMP-SP017 N/A
CAD files, wiring diagrams,
application files, and other
support information
