272 Rockwell Automation Publication IASIMP-QS019E-EN-P - August 2013
Appendix G Controller, Network, and Device Configuration Without the DMAT Wizard
The New Controller dialog box opens.
3. Configure the new controller.
a. From the Type pull-down menu, choose the controller type.
b. From the Revision pull-down menu, choose the revision.
c. Type the file Name.
d. From the Chassis Type pull-down menu, choose the chassis.
e. Enter the Logix5000 processor slot (leftmost slot = 0).
4. Click OK.
5. From the Edit menu, choose Controller Properties.
The Controller Properties dialog box opens.
6. Click the Date/Time tab.
7. Check Enable Time Synchronization.
This enables time synchronization for the
controller. Time synchronization is needed
for CIP Motion.
8. Click OK.
IMPORTANT All controllers and communication
modules must have time
synchronization enabled to participate
in CIP Sync.
