Chapter 7
System Application Guide
In this example, the Current trend is selected and the Y-axis
scale is adjusted accordingly.
3.
Press the trend configuration toolbar button
to set the
minimum and maximum values of the trend Y-axis scale.
The trend scale configuration screen opens.
4.
Press the value fields to modify.
A popup keyboard opens for value entry.
5.
Press the Enter key on the keyboard, when entry
is complete.
CIP Motion Drive
CIP Motion Drive
Value
Fields
CIP Motion Drive
