Rockwell Automation 9301 Series RSView32 Users Guide - Manual (Page 90)

4–10

RSView32 User’s Guide
To view a series of nested folders, resize the hierarchy box. To resize it,
place the cursor over the right border of the box until it changes to a
double arrow. Drag the border to the required size.
Duplicating a folder
When you duplicate a folder, all the tags in the folder are automatically
given the new folder name. If the folder contains folders, those folders
are also duplicated.
To duplicate a folder and its tags:
1. Select the folder in the hierarchy.
2. Click Duplicate Folder on the Edit menu or click the Duplicate
Tag Folder button on the toolbar.
3. In the To field, type the new folder name.
4. Click OK.
Be sure to choose Duplicate Folder rather than Duplicate. Duplicate
only duplicates individual tags. IMPORTANT
Duplicate
Tag Folder
