Keys
Operators can use the following keys to retrieve data from and send
data to the value table. You can re–assign these actions to other keys
or assign them to button objects.
PgDn: downloads the contents of all input fields in the active
graphic display to the value table
Ctrl–PgDn: downloads the contents of a selected input field to the
value table
Enter: downloads the contents of a selected input field to the
value table, unless the display was invoked using the /E parameter,
which disables the Enter key.
If the display has been set up to use the on-screen keyboard,
pressing Enter brings up the on-screen keyboard.
PgUp: uploads all values from the value table and displays them in
the input fields
Ctrl–PgUp: uploads a value from the value table for the selected
input field
Tab: moves between input fields
RSView32 commands
Operators can use these commands to retrieve data from and send
data to the value table:
Download: downloads the contents of the selected input field to
the value table
DownloadAll: downloads the contents of all input fields to the
value table
Upload: uploads a value from the value table and displays it in the
selected input field
