Creating graphic displays

11–57
4. Fill in the fields as follows:
5. Click OK.
Creating buttons
Use the Button tool to create buttons that work like standard
Windows buttons. You can attach RSView32 commands to the
buttons so they trigger actions when pressed and released.
You can apply visibility, color, horizontal and vertical slider, horizontal
and vertical position, width, and height animation to the button.
To create a button:
1. Click the Button tool.
2. Drag the mouse to draw a button about the size you want.
3. Release the mouse button.
In this field Do this
Expression Create an expression. At runtime, the numeric
result of the expression positions the arrow. For
details about expressions, see Chapter 14,
Creating expressions.
Range To use the minimum and maximum values for
the first tag in the expression, clear the Specify
check box. To specify a minimum and maximum
value that is different than the first tag’s, enter
values in the Min and Max fields.
Direction Select Vertical or Horizontal.
Button tool
Button tool
