6–28

RSView32 User’s Guide
Example: Creating a new file
To start a new file every Wednesday at 2:00 am and every Friday at
2:00 pm, type the following start times:
Creating files when a particular event occurs
1. Click On Event.
2. In the Expression field, create the expression that will trigger
creation of a new file. For details on creating expressions, see
Chapter 14, Creating expressions.
Example: Creating a new file for a new shift
You can set up your project so it creates a new log file at the end of a
shift or batch process. For example, create a tag called NextShift. In
the Alarm Setup editor, click On Event and then type NextShift as the
expression.
When the tag evaluates to true, a new alarm log file is created to store
the data from the new shift.
