9–2

RSView32 User’s Guide
Summary of steps
The main steps for configuring events are:
set up the evaluation interval for the event file in the Event Setup
dialog box
create the events in the Events editor
The Events editor
To open the Events editor:
1. In the Project Manager, open the Logic and Control folder.
2. Open the Events editor by doing one of the following:
double–click the Events icon
right–click the Events icon and then click New
