Animating graphic objects

12–23
2. Click the Width tab in the Animation dialog box.
3. Create an expression. The expression can be a tag name or a more
complex expression. If a tag name is used, the tag’s value
determines the object’s width.
4. Set the minimum width for the object by doing one of the
following:
click a handle on the left or right side of the object and drag it
to resize the object
type the width you want the object to be when the expression
evaluates to its minimum value
Select the At Minimum check box.
5. Set the maximum width for the object by doing one of the
following:
click a handle on the left or right side of the object and drag it
to resize the object
type the width you want the object to be when the expression
evaluates to its maximum value
Select the At Maximum check box.
6. Click an anchor point.
This is the part of the object that does not move. For example,
click Left if you do not want the left side of the object to move. As
the value of the expression changes, the object will grow to or
shrink from the right.
7. To specify minimum and maximum values, click the Specify check
box and type the values.
8. Click Apply.
