E–6

RSView32 User’s Guide
DH+ and DH–485 networks bridged by a
1785–KA5
Only bridging from DH+ to DH–485 is supported. The format of the
station address for nodes on the remote DH–485 network is:
Example: Bridging DH+ and DH-485 networks
The following figure shows an RSView32 system connected to a DH+
network with a KT–family card. The local DH+ network is bridged to
a remote DH–485 network using the 1785–KA5 communication
adapter.
The valid station entries for the various nodes in the figure are:
Station Address Valid Entries
ll.ss
lllocal bridge address
ssstation address on remote DH–485
Note: The 1785–KA5 link ID is not required
for addressing.
0 – 77 (octal)
0 – 37 (octal)
Only Enhanced SLC ™ 5/03 (OS 301) nodes are supported.
IMPORTANT
Station Address Valid Entries
7 (octal) 7
4 (octal) 4
10 (decimal) 17.12
11 (decimal) 17.13
