2–16

RSView32 User’s Guide
For the SOFT5 driver, enter the UNC name of the SoftLogix 5
controller without the backslashes. For example, if the UNC
computer name is \\ORION, type ORION. The computer name
must be 8 characters or less.
For SoftLogix 5 controllers using the AB_ETH driver, enter the
controller’s IP address.
Type
Select the type of device you are using.
To communicate with a SoftLogix 5 device you must use an
RSLinx driver and a TCP/IP channel.
Timeout
Type the number of seconds you want RSView32 to wait before
reporting a communication error. A timeout period of three
seconds is usually enough.
4. Click Accept to save the node configuration.
5. When you finish configuring nodes, click Close.
For this device type Select
PLC–2 PLC–2
PLC–3 PLC–3
PLC–5/10, PLC–5/12, PLC–5/15, PLC–
5/25 PLC–5
PLC–5/11, PLC–5/20, PLC–5/30, PLC–
5/40, PLC–5/60, PLC–5/80 PLC–5
(Enhanced)
SLC 5, SLC 5/01, SLC 5/02, SLC 5/03 (OS
300) SLC 5
SLC 5/03 (OS 301), SLC 5/04, SLC 5/05 SLC 5
(Enhanced)
SoftLogix 5 SoftLogix 5
