A–32

RSView32 User’s Guide
Examples: The Display command
Display Sample
The first time the graphic display called Sample is opened, it will be
positioned and sized as specified in its Display Settings dialog box.
When the display is closed, its size and position will be saved, so the
next time it is opened it will be the same size and position as when it
was last closed.
Display Picture /PNames /CB
Positions the graphic display called Picture in the bottom half of the
screen, using the file called Names to replace tag placeholders with
tag names.
Display Picture /H300 /W400 /CC
Makes the graphic display called Picture 300 pixels high and 400 pixels
wide, and positions the display in the center of the screen.
Example: Replacing tag placeholders in a graphic display
If a graphic display called Canning uses three tag placeholders, and
you want to substitute tags for canning corn, you would type:
Display Canning /Tcorn\off,corn\on,corn\weight
Placeholder #1 is replaced by the corn\off tag, placeholder #2 is
replaced by the corn\on tag, and placeholder #3 is replaced by the
corn\weight tag.
