12–60

RSView32 User’s Guide
To view the animation on an object using the menu:
1. Select an object.
2. View the animation by doing one of the following:
on the menu bar, click Animation and see which items have a
check mark
place the cursor over the object and press the right mouse
button to display the context menu. Then click Animation from
this menu and see which items have a check mark.
To view the animation on an object using the Animation
dialog box:
1. Select an object.
2. On the View menu, click Animation.
When the Animation dialog box opens, click the tabs to see which
types of animation have been set up.
The object
has visibility
animation.
