Configuring trends

13–29
\Paused A tag value of 1 pauses the trend.
A tag value of 0 resumes movement of the trend.
For real-time trends, RSView32 reads the value of this tag
when the trend is first displayed to determine whether to
start the trend in paused or resumed mode. If this tag
doesn’t exist, the trend is started in resumed mode.
For historical trends, RSView32 reads the value of this tag
when the trend is first displayed to determine whether to
start the trend in paused or resumed mode. If this tag
doesn’t exist, the trend is started in paused mode.
File-based trends are always started in paused mode.
Read and write
\PenMask A 16–bit mask that controls the visibility of the trend
pens. If the bit corresponding to a pen is set in this mask,
the pen is displayed. For example:
PenMask = 0000 0000 0000 0000 = 0
No pens are displayed.
PenMask = 0000 0000 0000 0100 = 4
Only Pen 3 is displayed.
Read and write
\StartTime Long integer tag specifying the time at the right margin of
the time scale.
The start time value is the number of seconds elapsed
since midnight (00:00:00), January 1, 1970, coordinated
universal time (UTC).
Read and write
\StartTimeDate String tag representing the start time and date for the
trend (at the right margin of the time scale). For example,
JAN 01 1998 13:00:00. Read and write
\TimeRange Time range of the time scale in seconds. Read and write
\Updating Digital tag that indicates whether the trend object is
retrieving data log data. The tag value is 1 if retrieving
data, and 0 if not. Read only
Tag name Function Read or Write?
