having to enter values one by one. Operators can then write all these
values to the programmable controller with another keystroke.
To create a recipe field:
1. Click the Recipe tool.
2. Drag the mouse to draw the field.
3. Release the mouse button.
4. In the Default File Name field, type the name of the recipe file to
and from which values will be saved and restored. Do not include a
file extension.
5. In the Field Length field, type a value to specify the maximum
number of characters that can be displayed in this field.
6. In the Justification field, select Left, Center, or Right to specify
how the recipe file name will be aligned within the field.
7. Click OK.
Creating a recipe file
A recipe file contains tag values for all the numeric and string input
fields in a graphic display. The recipe file uses index numbers to
specify which tag value goes into which input field.
A graphic display can have only one recipe field.
IMPORTANT
