Animating graphic objects

12–37
knob changes position accordingly. Likewise, when the slider’s knob
changes position (for example, by being dragged with the mouse) the
slider’s value is written to Tag1.
Not Bindable—When the tag value changes, the property value
changes. However, the reverse is not true. For example, if the slider
object described above has a property Value that is Not Bindable,
Tag1’s value will not change when the slider’s knob is changed but the
slider’s knob will change when Tag1’s value changes.
If a property is Not Bindable and read only, it does not appear on the
Animation tab of the ActiveX Property Panel.
To attach an RSView32 tag to a property:
1. Right–click the object, then click ActiveX Property Panel on the
context menu.
To open the property panel you can also right–click the object to
open the context menu, point to Animation, ActiveX Control, and
then click Properties.
2. Click the Animation tab if it is not already selected.
Click for help on the
selected property.
Drag splitter bar to see
more properties.
Click for help on the
property panel.
