E–8

RSView32 User’s Guide
The Pyramid Integrator (PI) link number for each DH+ network must
be unique. Use the 6200 Series Programming Software to configure
link numbers.
A PI chassis contains one RM module with two network channels. It
can also contain up to four KA modules, each with two network
channels. Using the RM and four KA modules, an RSView32 system
can communicate with programmable controllers on any or all of 10
DH+ networks.
Example: Bridging with a Pyramid Integrator
The figure on the following page shows an RSView32 system
connected to a DH+ network with a KT–family card. The PI routes
requests among four DH+ networks.
The valid station entries for the various nodes in the figure are:
Station Address Valid Entries
12 12
3 6:2.3
23 6:3.23
10 6:4.10
