11–20

RSView32 User’s Guide
Specifying display size
To set the display size, do one of the following:
select Use Current Size. When you save the graphic display, the size
of the window at that time becomes the default size.
select Specify Size in Pixels, and type values in the Width and
Height fields.
The window size and position you specify here can be overridden by
the RSView32 Display command. The Display command accepts size
and position parameters, which override the Display Settings options.
For more information about the Display command, see Appendix A,
RSView32 commands, or see Help.
Specifying resize behavior
Allow Display to be Resized
If you want a window that can be resized with the mouse, select this
check box. This option works with the pan and scale options.
If you do not select the check box, the graphic display cannot be
resized at runtime.
