6–62

RSView32 User’s Guide
The following table describes what the buttons do:
This
button
Does this
Ack
Current Marks the highlighted alarm as acknowledged. If a bell is
associated with the alarm, acknowledging the alarm turns off
the bell. If the tag has gone out of alarm, it is removed from
the alarm summary when it is acknowledged.
Ack Page Marks all alarms on the screen as acknowledged. If a bell is
associated with an alarm, acknowledging the alarm turns off
the bell. If a tag has gone out of alarm, it is removed from
the alarm summary when it is acknowledged.
Ack All Marks all alarms in the alarm summary as acknowledged. If a
bell is associated with an alarm, acknowledging the alarm
turns off the bell. If a tag has gone out of alarm, it is
removed from the alarm summary when it is acknowledged.
Silence
Current If the highlighted alarm is configured to set off the internal
bell, silences the computer’s sound.
If the highlighted alarm is configured to set off the external
bell, resets the associated bit in the programmable controller.
Silence
Page If any alarms on the screen are configured to set off the
internal bell, silences the computer’s sound.
If any alarms on the screen are configured to set off the
external bell, resets the associated bits in the programmable
controller.
Silence All If any alarms in the alarm summary are configured to set off
the internal bell, silences the computer’s sound.
If any alarms in the alarm summary are configured to set off
the external bell, resets the associated bits in the
programmable controller.
Execute Runs a command, macro, or VBA program, if one was
assigned to the Execute button. You can pass parameters
from the highlighted alarm (for example the tag name) to the
command, macro, or VBA program.
