E–2

RSView32 User’s Guide
Host name
When entering a host name, use one of the following:
a direct IP (Internet Protocol) address in the form
www.xxx.yyy.zzz where www, xxx, yyy, and zzz are numbers from
000 to 255
an alias for the address. An alias is an alphanumeric string from
one to eight characters. The first character must be a letter and the
name is case–sensitive.
Remote station addressing
This section outlines valid address entries for a node connected to a
remote network.
An RSView32 system can communicate with nodes on remote DH,
DH+, or DH–485 networks when connected to:
a DH+ network using a KT–family card (KT, KT2, KTX, KTXD,
PCMK)
a TCP/IP network using an Ethernet ® card
Remote DH or DH+ networks can be bridged by a 1785–KA
interface module or by a Pyramid Integrator
™ that has an RM or KA
module.
Remote DH–485 networks can be bridged by a 1785–KA5.
