13–38

RSView32 User’s Guide
Pen line color In the Trend dialog box, choose the Pen
Configuration tab, and then choose a color
in the Color field. You must configure each
pen separately. This color is also used for
the vertical axis labels and for the pen values
in the legend.
Pen line width Choose Line Properties from the Attributes
menu and then specify a width. If you use
this method the width applies to all the pens
in the trend.
Or, in the Trend dialog box, choose the Pen
Configuration tab and then choose a width
in the Custom Pen Width field. If you use
this method, you must configure each pen
separately.
If you do not specify a pen width, the pen
lines default to the width selected for the
grid lines.
Pen line symbol In the Trend dialog box, choose the Pen
Configuration tab and then choose a symbol
in the Show Plot Symbol field. You must
configure each pen separately.
To choose Do this
