Configuring trends

13–39
Using the trend at runtime
Selecting pens
To display details about a pen, select the pen by clicking it in the
legend. When the pen is selected, the vertical scale changes to reflect
the minimum and maximum values for that pen.
Marker color Choose Font from the Attributes menu and
then choose a color. For information about
the marker see page 13-41.
The marker color is also used for time axis
labels (if used) and for the time and date in
the legend.
Text font family, size, and
color Choose Font from the Attributes menu and
then choose a font, size, and color. The font
and size are used for all the text used for
axis labels and all the text in the legend.
The font color is used for time axis labels (if
used), for the time and date in the legend,
and for the marker color.
To choose Do this
