Message mnemonics – Rockwell Automation 9301 Series RSView32 Users Guide User Manual
Page 732
D–34
RSView32 User’s Guide
Message mnemonics
Mnemonic
Instruction
Type
Submember Range
AD
Done
Digital
AE
Error
Digital
CO
Continuous
Digital
DATA[]
Reserved / Internal Use
Analog
0 – 51
DLEN
Done Length
Analog
DN
Synchronization Done
Digital
EN
Enable
Digital
ER
Synchronization Error
Digital
ERR
Error Code
Analog
EW
Enable Waiting
Digital
NR
No Response
Digital
RLEN
Request Length
Analog
ST
Start Transmission
Digital
TO
Time Out
Digital
