Creating graphic displays

11–33
You can also use the Arc and Wedge tools to reshape any arc, ellipse,
or wedge.
Creating text
1. Click the Text tool.
The pointer becomes an I–beam ( ).
2. Type the text.
Once the Text tool is selected, you can create more than one text
object. To do so, move to an empty spot in the drawing area, click,
and then type the text.
To edit text, select the text object and double–click. The I–beam
appears. To delete text characters, use the Backspace and Delete
keys.
You cannot rotate text.
Choosing a font
You can choose a font before or after you create text. Fonts apply to
all objects, including display and input objects.
1. Select the text object or objects you want to format, or position the
I–beam where you want to begin typing text.
2. On the Attributes menu, click Font.
Text tool
Text tool
