Rockwell Automation 9301 Series RSView32 Users Guide User Manual
Page 731
Addressing syntax for Allen–Bradley programmable controllers
D–33
MINS
Setpoint Minimum
Analog
MO
Mode
Digital
OLH
Output Limit High
Digital
OLL
Output Limit Low
Digital
OUT
Output
Analog
PE
PID Equation
Digital
PV
Process Variable
Analog
PVDB
Process Variable Alarm Deadband
Analog
PVH
Process Variable Alarm High
Analog
PVHA
Process Variable High Alarm
Digital
PVL
Process Variable Alarm Low
Analog
PVLA
Process Variable Low Alarm
Digital
PVT
Process Variable Tracking
Digital
SO
Set Output %
Analog
SP
Setpoint
Analog
SPOR
Setpoint Out of Range
Digital
SWM
Software A/M Mode
Digital
TIE
Tieback %
Analog
UPD
Update Time
Analog
Mnemonic
Instruction
Type
Submember Range
