11–8

RSView32 User’s Guide
Selecting and deselecting objects
To work with an object, you must first select it with the Select tool.
You can click this tool in the Drawing Tools toolbox or on the Objects
menu.
To deselect a drawing tool, click the Select tool in the toolbox or on
the Objects menu.
Using the grid
To size and position objects precisely, use the grid items on the View
menu. You can change the grid settings any time during the drawing
process.
Select tool Select tool
To select Do this
An object Click the object.
Several objects Click the first object, Ctrl–click additional
objects.
All objects in an area Drag diagonally to draw a selection border
around the objects.
Ctrl–click objects outside the border to add
them to the selection.
All objects in the drawing
area Click Select All on the Edit menu.
To deselect Do this
An object Ctrl–click the object.
Several objects Hold down Ctrl and drag a selection border
around the objects.
All selected objects Click in the drawing area, away from any
objects.
