11–100

RSView32 User’s Guide
Flipping objects
Flipping an object creates a mirror image of that object. You can flip
most objects.
1. Select an object.
2. Click the appropriate button or menu item:
Select objects Space vertically
Centers are
separated by
an equal vertical
distance
Select objects Space horizontally
Centers are separated
by
an equal horizontal
distance
This button or
menu item
Flips selected objects
Flip
Vertical Top to bottom (upside–down)
Flip
Horizontal Left to right
