12–38

RSView32 User’s Guide
The middle column indicates whether the property updates the tag
or the tag updates the property:
A left arrow indicates the tag updates the property
A right arrow indicates the property updates the tag
A double arrow indicates the tag and property update each
other
3. Click in the Tag column to specify the tag to use for the property.
Type the tag name or click the ... button to open the Tag Browser
and select a tag.
Attaching ActiveX control events
The ActiveX Control Events dialog box shows the events associated
with the selected ActiveX object and allows you to specify RSView32
commands or macros that will run when the event occurs at runtime.
For more
information
about the object
and its events,
click this button.
To launch the
Command
Wizard, click
this button.
