12–34

RSView32 User’s Guide
The object’s properties versus RSView32
animation
Each ActiveX object has a set of properties. To view the object’s
properties, right–click the object, then click ActiveX Property Panel
on the context menu. The content of the property panel is determined
by the application that created the object, not by RSView32.
To link the ActiveX object to RSView32, you must attach ActiveX
control to the object.
To configure ActiveX control:
1. Right–click the object to open the context menu, point to
Animation, ActiveX Control, and then click the control you want.
You can also use the Animation menu on the Graphic Display
editor’s menu bar. Click Animation, point to ActiveX Control, and
then click the type of control you want.
The runtime behavior of ActiveX objects depends on the vendor’s
implementation. Before running your project, test ActiveX objects
thoroughly to ensure they behave as desired. IMPORTANT
