Importing and exporting XML files

F–3
Importing graphic XML file
You can import one single graphic display XML file at a time. You can
also choose whether to create a new display or update an existing
display.
To import graphic display information from an XML file
1. In RSView32, click the Project menu.
2. On the Project menu, click Graphics Import Export Wizard.
3. Follow the instructions in the wizard.
For more information about using the Graphics Import Export
Wizard, see the RSView32 online help.
Graphic display XML file structure
The RSView32 XML document is an XML file that describes the
objects and settings for a graphic display. The root element of the
XML document is called GFXDocument. It represents the graphic
display. An XML document can contain only one root element. All
other elements in the document must be contained or nested within
the root element.
In an XML document, the start of an element is marked name>. The end is marked .
Here is a sample structure for a graphic display XML document
containing one graphic object.
Element Description
Root element.
Contains properties of the display.
