Animating graphic objects

12–53
Example 3: Opening an object–specific alarm summary
Imagine you want to have alarm information available for a specific
machine. If something goes wrong and causes an alarm, you want the
operator to be able to display an alarm summary for that machine.
1. Create an alarm summary that uses a filter to display only the
alarms for the machine. For more information about creating an
alarm summary, see page 6-54.
2. In the Display Keys dialog box, assign a display key. In the Press
Action field, type
Display AlmSumm /t[tag]
.
3. In the Object Keys dialog box, type the name of the alarm
summary file in the Current [Tag] field for each machine object.
