Station addressing for nodes connecting to Allen–Bradley devices

E–11
if connected on a KA, type: mKA:n
where m is the pushwheel number (1 to 4) on the KA and n is the
KA channel number (2 or 3).
station_address is one of the following:
Remote Network Station Address Valid Entries
DH lll local station address 0 – 376 (octal)
DH+ ll local station address 0 – 77 (octal)
DH bridged by a
1785–KA module ll.sss
ll local bridge address
sss station address on remote DH+
0 – 77 (octal)
0 – 376 (octal)
DH+ bridged by
two 1785–KA
modules ll.rrr.ss
ll local bridge address
rrr remote bridge address
ss station address on remote DH+
or
ll.rss
ll local bridge address
rss combined remote bridge address and
remote station address
The address ll.rss is an offlink address that is
shortened by combining the remote bridge and
remote station addresses into one three–digit
number. The system reads only the first digit of
the remote bridge address, and adds the two–digit
remote station address to produce a shorter
address that still points to the same node.
0 – 77 (octal)
0 – 376 (octal)
0 – 77 (octal)
0 – 77 (octal)
0 – 376 (octal)
