Configuring data logging

7–11
The Data Log Setup editor
To open the Data Log Setup editor:
1. In the Project Manager, open the Data Log folder.
2. Open the Data Log Setup editor by doing one of the following:
double–click the Data Log Setup icon
right–click the Data Log Setup icon and then click New
Setting up a model
1. In the Data Log Setup editor, click the Setup tab.
2. Type a description of the model. This is for your information only.
3. Specify whether to use long file names for the data log files.
If you choose to use long file names, type a log file identifier string,
up to 20 characters. This string of text forms part of the file name
Set up general aspects
of the model.
Specify when you
want log data
created and deleted.
Specify how and
when logging
should occur.
Specify which tags
to log data for.
Specify the paths to
which to log the
data.
