Rockwell Automation 9301 Series RSView32 Users Guide User Manual
Page 572
16–10
RSView32 User’s Guide
TransType
The type of alarm that was generated. The types are:
InAlmIn Alarm (severities 1 through 8)
OutAlmOut of Alarm
AckedAcknowledged
RmAckRemote Acknowledged
InFltIn Fault
OutFltOut of Fault
SupOnSuppress On
SupOfSuppress Off
TagName
The name of the tag or alarm event that caused the
alarm.
TagValue
The value of the tag at the time the alarm occurred.
TagType
The type of tag in alarm: A for analog, D for digital, S for
string.
ThreshVal
The threshold value.
ThreshNum
The threshold number.
ThreshLabl
The threshold label.
Severity
The alarm severity (1 is highest severity and 8 is lowest
severity).
DstFlag
The Daylight Savings Time (DST) flag, where Y means
DST is in effect and N means DST is not in effect. This
number is for RSView32 internal use only.
UserId
The user that was logged on when the alarm occurred.
AlarmType
The number RSView32 assigns to the transaction type.
Dscription
The message that is associated with the transaction
(alarm) type.
This column
Contains
